Specifications
| （Engine Model） | 6DH1-24E5 | 6DH1-22E5 | 6DH1-20E5 | 6DH1-18E5 | 6DH1-16E5 |
| Engine Displacement | 5.7L | ||||
| Bore × Stroke(mm ) | 98×126 | ||||
| Engine Type | In-line 4-cylinder, four-stroke, water-cooled, turbocharged with intercooler | ||||
| （Valve Train） | Overhead Camshaft (OHC), 4-valve per cylinder | ||||
| Rated Power / Speed(kW/rpm) | 179/2500 | 165/2500 | 150/2500 | 135/2500 | 121/2500 |
| Maximum Torque / Speed(N·m/rpm ) | 900/1300-1700 | 850/1300-1700 | 850/1300-1700 | 850/1300-1700 | 650/1300-1700 |
| Minimum BSFC at Full Load(g/kW·h) | ≤207 | ≤207 | ≤207 | ≤207 | ≤207 |
| Low-speed Torque at 800 rpm（Nm） | 600 | 600 | 600 | 600 | 600 |
| Fuel System | FCRI 2000bar common rail system | ||||
| Oil to Fuel Consumption Ratio | 1 ‰ | ||||
| Noise Level at 1 MeterdB(A) | 94 | ||||
| B10 Life(km) | 80 | ||||
| Weight(kg) | 570 | ||||
| Length × Width × Height（mm） | 1062×750×956 | ||||
