Technical Characteristics
Long Service Life
B10 life of 500,000 km, with extended oil change interval of 50,000 km
Low Noise
Fine-tooth gear design with gear accuracy grade 8, resulting in lower noise
High Load Capacity
Auxiliary box center distance: 110 mm, maximum torque: 1000–1100 Nm
Lightweight Design
Twin countershaft structure with main and auxiliary gearbox, front-rear split housing
Fuel Efficiency and Economy
FAW engine-transmission-axle efficient powertrain, small step ratio improves overall fuel economy.(Saves approximately ¥2520 per year at an annual mileage of 100,000 km and diesel price of ¥6.3/liter)
Parameter Table
| Item | CA8TAX090M | CA8TAX090M1 |
| Input Torque（Nm） | 1000 | 1100 |
| Center Distance（mm） | Main Box ：110；Auxiliary Box ：110 | |
| Gear Ratio Range | 13.019（9.569~0.735） | 9.674（7.323~0.757） |
| Weight（kg） | 185（Bottom Push）/183（Side Push） | |
| Installation Length（mm） | 725.3/737.7/755 | |
| Overall Efficiency | 97.13% | |
| Noise Level（dB） | ≤87.48 | ≤89 |
