Specifications
| Model | CA6DM3-46 | CA6DM3-55E | CA6DM3-52E | CA6DM3-56E | |
| Type | 6-cylinder in-line, direct injection, turbocharged&intercooling, common rail | ||||
| Bore× Stroke (mm ×mm) | 126.5×166 | ||||
| Valve number | 4 | ||||
| Total displacement (L) | 12.52 | ||||
| Rated power/speed (kW/r/min) | 341/1800 | 407/1800 | 386/1800 | 415/1800 | |
| Net power/speed (kW/r/min) | 338/1800 | 404/1800 | 383/1800 | 412/1800 | |
| Max torque/speed (N. m /r/min) | 2200/1100～1400 | 2300/1100～1300 | 2500/1100～1400 | 2600/1100～1400 | |
| Min. fuel consumption at full load (g/kW. h ) | 186 | ||||
| Technical Route | National Five SCR independent common rail + cancellation of after-treatment | National VI SCR independent common rail + cancellation of post-treatment | |||
| Emission Compliant (TAS) | Country 2 | No emission requirements | |||
Globally Leading Intelligent Power Solutions
We have delivered over 280,000 high-performance engines to 67 countries and regions worldwide. Explore intelligent manufacturing and reliable power to create greater value for your business.
