Specifications
| Model | CA6DM3-48E6 | CA6DM3-50E6 | CA6DM3-52E6 | CA6DM3-56E6 |
| Type | 6-cylinder in-line, direct injection, turbocharged&intercooling, common rail | |||
| Bore× Stroke (mm ×mm) | 126.5×166 | |||
| Valve number | 4 | |||
| Total displacement (L) | 12.52 | |||
| Rated power/speed (kW/r/min) | 356/1800 | 370/1800 | 386/1800 | 415/1800 |
| Net power/speed (kW/r/min) | 353/1800 | 367/1800 | 383/1800 | 412/1800 |
| Max torque/speed (N. m /r/min) | 2300/1300 | 2300/1300 | 2500/1300 | 2600/1300 |
| Min. fuel consumption at full load (g/kW. h ) | 186 | |||
| Technical Route | EGR+DOC+DPF+SCR+autonomous system | |||
| Emission Compliant (TAS) | Ⅵ（EⅥ E） | |||
| Model | CA6DM3-48E66 | CA6DM3-50E66 | CA6DM3-52E66 | CA6DM3-56E66 | |
| Type | 6-cylinder in-line, direct injection, turbocharged&intercooling, common rail | ||||
| Bore× Stroke (mm ×mm) | 126.5×166 | ||||
| Valve number | 4 | ||||
| Total displacement (L) | 12.52 | ||||
| Rated power/speed (kW/r/min) | 356/1800 | 370/1800 | 386/1800 | 415/1800 | |
| Net power/speed (kW/r/min) | 353/1800 | 367/1800 | 383/1800 | 412/1800 | |
| Max torque/speed (N. m /r/min) | 2300/1300 | 2300/1300 | 2500/1300 | 2600/1300 | |
| Min. fuel consumption at full load (g/kW. h ) | 178 | ||||
| Technical Route | DOC+DPF+SCR+autonomous system | ||||
| Emission Compliant (TAS) | National VI | National VI (obtained EU VI D certification) | |||
Globally Leading Intelligent Power Solutions
We have delivered over 280,000 high-performance engines to 67 countries and regions worldwide. Explore intelligent manufacturing and reliable power to create greater value for your business.
